Product Description
Details
Features:
Rotation-stop for light chiselling applications in brick, soft masonry and occasionally concrete
Impact-stop for drilling in wood, steel, ceramic and screw driving applications
Large hammer mechanism delivers high performance with low stress to the critical components resulting in better durability
Mechanical clutch eliminates sudden high-torque reaction should the bit jam
Electronic variable speed for total control in any application
Rounded ergonomic industrial design allows easy and comfortable handling in any application
Improved sealing for maximum protection from dust ingress ensuring long tool life
Output air slots designed to protect users' eye
Specification:
Power Input: 710 Watts
No Load Speed: 0-1550 rpm
Blows per Minute: 0-5680 bpm
Impact energy: (EPTA 05/2009) 2.0 J
Tool Holder: SDS-Plus
Max. Drilling Capacity: [Wood] 30 mm
Max. Drilling Capacity: [Metal] 13 mm
Max. Drilling Capacity: [Concrete] 22 mm
Max. Drilling Capacity: [Core bit] 50 mm
Length: 330 mm
Height: 210 mm
Sound Pressure: 89 dB(A)
Sound Pressure Uncertainty: 3.8 dB(A)
Sound Power: 100.1 dB(A)
Sound Power Uncertainty: 3.8 dB(A)
Hand/Arm Vibration - Hammer drilling into concrete: 13.6 m/s_
Hand/Arm Vibration - Chiselling: 12.5 m/s_
Hand/Arm Vibration - Drilling into metal:
Hand/Arm Vibration - Screw driving without impact:
Uncertainty K 1 (Vibration): 1.5 m/s_
Weight: 2.5 kg
